Inovenso NanoSpinner24

Inovenso NanoSpinner NS24

The NS24, is Inovenso’s most versatile and advanced laboratory-scale system. It is also our best-selling model with more than 50 units installed in renowned universities and companies around the globe. This Electrospinning unit enables the collection of the nanofibers on a variety of collectors: a Flat collector, a Rotating drum collector with a high speed of 2000 rpm for obtaining well-aligned nanofibers. It can also optionally accommodate a Rotating rod collector with different sizes to obtain tubular structures of nanofibers known as tube-like nanofibers membranes, which can be used as artificial blood vessels. The Inovenso NanoSpinner NS24 has 12 nozzles, but can also be used with a single nozzle for small-laboratory production.

  • Reliable and precise process adjustments via 9” touch screen panel
  • High throughput production
  • Up to 12 electrospinning nozzles feeding
  • 376.8 mm*280 mm nanofibre coating area
  • High-speed rotating drum up to 2000 RPM
  • Production of oriented or aligned nanofibers
  • Adjustable horizontal movement to increase the uniformity of the membrane
  • Automatic adjustable spinning distance
  • Extra safety options such as a safe door and a warning light to avoid high voltage
  • Produced according to safety regulations and CE Certified
  • Precise Electrospinning/Spraying Process Adjustments Via 9” Touch Screen

Inovenso NanoSpinner NS24

The NS24 is Inovenso’s most versatile and advanced laboratory-scale system. It is also our best-selling model with more than 50 units installed in renowned universities and companies around the globe. This Electrospinning unit enables the collection of the nanofibers on a variety of collectors: a Flat collector, a Rotating drum collector with a high speed of 2000 rpm for obtaining well-aligned nanofibers. It can also optionally accommodate a Rotating rod collector with different sizes to obtain tubular structures of nanofibers known as tube-like nanofibers membranes, which can be used as artificial blood vessels. The Inovenso NanoSpinner NS24 has 12 nozzles, but can also be used with a single nozzle for small-laboratory production.

  • Reliable and precise process adjustments via 9” touch screen panel
  • High throughput production
  • Up to 12 electrospinning nozzles feeding
  • 376.8 mm*280 mm nanofibre coating area
  • High-speed rotating drum up to 2000 RPM
  • Production of oriented or aligned nanofibers
  • Adjustable horizontal movement to increase the uniformity of the membrane
  • Automatic adjustable spinning distance
  • Extra safety options such as a safe door and a warning light to avoid high voltage
  • Produced according to safety regulations and CE Certified
  • Precise Electrospinning/Spraying Process Adjustments Via 9” Touch Screen
The 9” touch screen panel offers reliable and precise process adjustments, which significantly benefits users in several ways:

Ease of Use:

The intuitive interface simplifies the operation, making it accessible even for those with minimal technical knowledge.

Precision: Fine-tuning settings directly on the touch screen allows for accurate control over process parameters, enhancing the quality and consistency of results.

Efficiency: Quick adjustments and real-time feedback streamline workflows, reducing downtime and increasing productivity.

User Experience: The large screen provides clear visuals and easy navigation, improving overall user satisfaction.

These benefits ensure that users can effectively manage and optimise their processes with minimal effort.
  • Precise Electrospinning Process Inovenso Lab Scale Electrospinning/Spraying Touch Screen
  • Remote Monitoring and Control System
  • Inovenso Lab Scale Electrospinning/Spraying Machines Remote Control via WiFi
NE Series electrospinning devices now come equipped with an advanced remote monitoring and control system, offering the following capabilities:

Wi-Fi Connectivity: The device includes a Wi-Fi adapter for easy connection to your local network.

Comprehensive Monitoring: Our remote software monitors all process parameters in real-time.

Full Control: You can control all process parameters remotely using our intuitive software.

BatchID Management: Save and access process parameters with BatchID for future reference.

Extended Storage: Store used parameters for a minimum of six months.

Graphical Data Display: View parameters used in transactions graphically, associated with BatchID.

User Authentication: Ensure secure access with user authentication in the software.

Activity Logs: Record every activity on the device, both remote and local, as a log with BatchID.

Log Monitoring: Monitor system logs to ensure operational integrity.

Fault and Alarm Management: Save every fault and alarm message, and notify active remote users instantly.

Save Time And Experience The Ease of Using Up To 12 Hybrid Nozzles

The NanoSpinner24 is a cutting-edge electrospinning device engineered for high-efficiency nanofiber production. This versatile machine excels with its innovative 12 hybrid nozzle configuration, allowing for the simultaneous production of multiple nanofiber streams, thus significantly boosting output and uniformity. Additionally, the NanoSpinner24 offers flexibility with single, triple, and six-nozzle configurations, catering to a wide range of research and industrial applications.

Precision and Control: Each configuration allows precise control over the electrospinning parameters, ensuring high-quality and consistent nanofiber production.

Innovative Design: The hybrid nozzles are designed to handle various polymer solutions, providing flexibility in the types of nanofibers that can be produced.

Inovenso Nanospinner NS24 12 Nozzles Electrospinning Machine

Fully Safe Electrospinning Machine Experiment

Inovenso’s electrospinning machines are designed with advanced safety features to ensure a safe and secure operating environment for users. Key safety options include the safe-door and warning light systems, which help mitigate risks associated with high voltage during the electrospinning process.

Enhanced User Protection: Both the safe-door and warning light systems significantly reduce the risk of electrical accidents, protecting users from potential harm.

Compliance with Safety Standards: These safety features help ensure that Inovenso’s machines comply with international safety standards and regulations, providing peace of mind to users and institutions.

Operational Efficiency: By preventing accidental interruptions and ensuring safe operation, these features contribute to the overall efficiency and reliability of the electrospinning process.

User Confidence: Enhanced safety measures increase user confidence, allowing researchers to focus on their work without concerns about safety risks.

Optional Accessories
  • Different Diameter Needles
  • Bicomponent System
  • Gas Shield Nozzle
  • Rotating Shaft Collector
  • Vacuum Holder Plate Collector
  • Climate Controls
  • Negative High Voltage Power Supply
  • Camera Integration
  • Carbon Filter
  • Extended Warranty
