TITOMIC Integrated Spray Booths
Industrial custom cold spray booths & integrated systems. Titomic integrated spray booths (ISBs) bring together low-pressure cold spray, handling and dust extraction, and can be customised to your specific needs.
Features
- Robotics or linear system
- Integrated dust suction system
- Automated parts loading and unloading
- Compatible with different powder feeders
- Remote access for service
- Data logging
- Closed-loop cold spray
System
- ISB 11 Model
- D523 low-pressure cold spray system
- Robotics or linear system
- Remote access for service
- Data logging
- Closed-loop cold spray
- Integrated dust suction system
- Automated parts loading and unloading
- Compatible with different powder feeders
Specifications
Spray Cabinet
- 1500 x 1500 x 2200 mm
- Doors with a security lock
Lights - Touch Screen for integrated
- Cold Spray and Linear Control
- Connection for the Dust suction unit
D523 Cold Spray System
- Cold Spray Gun & Heater
- PLC Process Monitoring
- Parameter storage
Linear System
- X, Y – 700 x 600 mm
- X, Y speed max. 300 mm/sec
- Holder for Cold Spray gun
Dust Suction Unit (Filterbox 12A)
- 1200 m3/hr
- Filter efficiency, with HEPA, 99,95%
- Sound level 74 dB
- Automatic Filter Cleaning (compressed air)
- Dimensions: 800 x 1370 x 1280 mm
Options
- Z-ax, 250 mm
- Integrated chuck for rotating parts, Ø 125 mm
- PB-95, pressurised powder feeder
Based on the ISB 11 model
