ISI-SYS VIC-2D

VIC-2D

The Vic-2D System – Vic-2D can measure in-plane displacements and strains on planar specimens. The setup is simple, for sample preparation, only the application of a random speckly pattern is necessary. No special illumination or lasers are required.

We offer complete measurement systems for a wide range of full-field in-plane deformation measurement tasks.

  • White-light system
  • No calibration required
  • Real-time data processing (> 50Hz)
  • Sample size <1mm and >10m possible
  • Simple specimen preparation using paint
  • Synchronised load data acquisition
  • Available analogue output for machine control
  • Very high strain and displacement limits

VIC-2D System

The Vic-2D System – Vic-2D can measure in-plane displacements and strains on planar specimens. The setup is simple, for sample preparation, only the application of a random speckly pattern is necessary. No special illumination or lasers are required.

We offer complete measurement systems for a wide range of full-field in-plane deformation measurement tasks.

  • White-light system
  • No calibration required
  • Real-time data processing (> 50Hz)
  • Sample size <1mm and >10m possible
  • Simple specimen preparation using paint
  • Synchronised load data acquisition
  • Available analogue output for machine control
  • Very high strain and displacement limits

We also provide components as well as custom measurement systems for demanding applications, including high temperature, higher speeds, and very small- or large-scale samples.

Application

The system is used where strain distributions need to be measured on flat specimens. Applications include fracture mechanics (COD measurement), bi-axial tension tests of films, determination of strain localisation around cracks or notches, as well as many applications in FE model verification.
